The 3DX-RAY Threat Scan®-LSC is a portable x-ray inspection system that includes two (2) panels: the large format LS1 panel and the compact LS3 panel.

3DX-RAY Threat Scan®-LSC

(No reviews yet) Leave a Review

For more information / pricing please call 800-533-0144 or email

Part #:



The 3DX-RAY Threat Scan®-LSC is a portable x-ray inspection system that includes two (2) panels: the large format LS1 panel and the compact LS3 panel.

The LS1 panel has a large imaging area of 600mm x 460mm to scan typical bags and packages in one scan, yet is still remarkably lightweight and incredibly thin.

The LS3 panel is more compact with an imaging area of 305mm x 256mm, for use where access to suspect packages is limited or under vans, for example.

This combination system is powerful and can penetrate steel up to 40mm at 120kV and up to 60mm at 150kV. It also produces high quality, sub-millimetre resolution images.

The ThreatScan®-LSC system includes a backpack and a compact cable set as standard.

The ThreatScan® range is suitable for use in suspect bag and package inspection in locations such as mass transit rail and bus stations, shopping malls, airports, stadia and sports arenas. The system is also used for general security inspection by first responders such as Police, Military and Private and Government Security agencies.





  • Two detector panels as standard
  • Backpack and cable set included
  • High penetration with sub-millimetre resolution (120kV or 150kV generator)
  • Real-time images
  • Designed for rapid deployment and ease of use
  • Powerful image enhancement and analysis tools
  • Intuitive, user-friendly ThreatSpect software
  • Scans virtually to the floor (3mm above floor level)








A large and compact panel included

EOD evaluation

Customs control

Vehicle scanning

Suspect item inspection

Portable, real-time x-ray scanning system

ThreatScan®-LSC is a lightweight, portable, battery powered dual x-ray scanning system designed in co-operation with first responders and EOD teams to meet the needs of the field operative.

Quick and simple to deploy, the system produces high quality real-time x-ray images for rapid and accurate decision making.

A detector panel is positioned behind the target; the generator is placed in front.

The scan is activated from the imaging station.

The large 600mm x 460mm imaging area of the LS1 panel enables the operator to scan typical bags and packages in a single scan.

The smaller 305mm x 256mm imaging area of the LS3 panel still enables the operator to scan suspect items in a single scan.

The I-Gen can penetrate steel up to 40mm at 120kV and up to 60mm at 150kV.

The LSC system produces sub-millimetre resolution images and there is a range of sophisticated image processing functions available including materials discrimination, pan, zoom, DeepFocus™, 3D Emboss, measurement and annotation, coupled with high quality images enable the operator to interpret the image quickly and accurately.

The software can also communicate the image on screen to a remote command centre and save images in JPEG and other common file formats.

The standard package comprises a large format panel, compact panel, 120kV or 150kV x-ray generator, tablet pc, ThreatSpect software, batteries, chargers, wireless communication, back pack, cable set and transport cases.

Options include tripod, repeater stations, spare batteries and chargers, soft carry cases, wired and fibre optic cable sets.

Ideal for use by First Responders, EOD teams, Counter Surveillance, and Customs and Security Operatives

Sub range enhancement function

X-ray of drugs in pipes in fuel tank

LS1 comparison with 14”x17” detector

Set of IED devices




X-Ray Detector Panels (LS1 and LS3)

Image / detector resolution

LS1: 1152 pixels, 40AWG / LS3: 640 pixels, 40AWG (400 micron)

Dynamic range

65536 (16-bit)

Image acquisition / scan speed

LS1: 5 seconds / LS3: 2.7 seconds

Detector dimensions

LS1: 753mm x 478mm x 25mm (external) (L x H x D)LS3: 462mm x 273mm x 35mm (external) (L x H x D)

Imaging / scanning area

LS1: 600mm x 460mm / scans to 3mm above floor levelLS3: 305mm x 256mm / scans to 3mm above floor level


LS1: 5kg (5.5kg with battery) / LS3: 2.7kg (3.2kg with battery)


Self contained rechargeable lithium ion battery (8-hr standby)

Communication protocols

Wireless 802.11 a/b/g/nWired or fibre optic options, TCP/IP ethernet

Operating temperature

-20˚C to +55˚C / MIL-STD-810F 501.4 and 502.4


Wireless (as standard)

802.11g / up to 120m range (extendable with repeaters)

Fibre optic (option)

100m, 150m, 200m

Ethernet (option)

25m, 50m

Imaging Station*


Standard tablet pc (ruggedised options available)* PC specification to be confirmed and agreed at order stage

Operating System

English MS Windows


Mains and battery

Software Features

Adjustable x-ray source parameters (kV, mA & time)

Standard, Inverted and False Colour images

Rotate, Histogram, Pan, Zoom, DeepFocus™

On-screen Measurement and Annotation (options)

Materials Discrimination and 3D Emboss (options)

Image Stitching (option)

Multi-file format import (option)

Multi-touch functionality for tablet based operation (option)


Physical safety interlock plus key switch

Audible & visible warning signs

CE compliant

Certification & Codes


Codification NSN 6350-99-170-6036
