Product Type: 2 CH Wireless Remote Switch Transmitter + 1CH Receiver
Coded System: 1527 Learning Code
Working Mode: Momentary, Toggle, Latching and Time Delay Mode.
Modulation Mode: ASK
Operating RF Frequency: 433MHz
Input Voltage: 12 V, RF working mode: Superheterodyne
Receiver sensitivity: > 97 dbm
Transmitting distance: > 100 m ( open space)
Decoding mode: MCU software decoding
Remote storage: 20
Support remote type: EV1527 learning code
Output terminal: NO , NC , COM
Dimension of PCB: 35 x 30 x 18 mm (L,W,H)
Remote control battery: 2 x 3 V CR2016 button batteries
Note: Maximum input power is 250 V
Note：Instructions for use attached to the picture
1 x Transmitters 1 x Receiver
