please contact us for pricing and availability to government agencies only
NOT AVAILABLE FOR EXPORT. FOR GOVERNMENTAL USA END USERS ONLY. THANK YOU.
The CEIA CMD is a very high performance, high-sensitivity Compact Metal Detector designed to detect metal and minimum-metal content targets in conductive and non-conductive soils, including laterite and magnetite. Pinpointing of the metal objects is aided by an evolved system of acoustic modulation and an LED bar indicator.
The Metal Detector consists of a search head, a control unit, a telescopic pole and an elbow support jointed together in a one-piece design. The detection head is light and the wiring is designed to be protected from any possible damage.
The one-piece foldable design allows the CEIA CMD Metal Detector to be operational in a very short time and to be carried easily everywhere.
The detector is equipped with a built-in Ni-MH battery charger which allows the batteries to be recharged (in 3 hours. max) without the need to extract them from the unit. This also allows full environmental protection of components and maximum operational speed for the user.
Intentionally designed to be used easily and comfortably in every working condition, the CEIA CMD can be set up for operation in less than twenty seconds.
The Metal Detector offers the best combination of functional and operational characteristics. More specifically, it provides the highest ratio between overall dimensions, detection depth and operational weight.
The length of the telescopic pole can be adjusted for operation in upright, kneeling or prone positions.
The CEIA CMD does not require any manual calibration; in addition, optimum sensitivity is ensured over all types of terrain due to CEIA’s Exclusive Automatic Soil Compensation System.
Localization of metal objects is optimized by an Acoustic Modulation pinpointing system aided by a Visual LED bar graph, which allows the position of the detected mass to be identified accurately.
If desired, the led bar can be masked with a snapdown cover so as to avoid remote visibility (stealth operations).
CEIA provides complete support for technical and operational courses, given by certified personnel, either on site or at its own premises.
The curriculum includes first and second line maintenance, training for operators and a course for operator instructors:
The watertight control unit and search head withstand the most stringent environmental requirements and Standards.
All controls are within easy reach of the operator:
V1:
POWER SUPPLY Types of batteries (2x), ANSI Standard, type C
1.2V Ni-MH rechargeable - 1.5V Alkaline (LR14)
BATTERY LIFE AT 20°C
(DEFAULT SEARCH
PROGRAM)
with Ni-MH (6000 mAh) rechargeable batteries: 8 hours
with alkaline batteries: 6 hours
Battery charge indicator
METAL ALARM Adjustable sensitivity
Audible alarm with adjustable volume and visual LED display
(maskable with a snap-down infrared cover)
DIMENSIONS Search head: 13.78" x 5.51"
Folded Metal Detector: 15.24" x 6.18" x 3"
Fully extended: 50.79" mm
Carry bag: 15.55" x 7.87" x 4.33"
WEIGHT Metal Detector without batteries: 4.37 lbs
batteries included: 4.63 lbs
Carry bag: 1.19 lbs
Headphone: 6 oz
OPERATING
TEMPERATURE -50.8 °F to +158 °F
STORAGE
TEMPERATURE -67 °F to +185 °F
LEVEL OF
PROTECTION
IP68 (IEC 529)
Carry bag in water resistant synthetic canvas
SET-UP TIME Twenty seconds typical (batteries already in place)
BUILT-IN
BATTERY CHARGER
POWER SUPPLY
90-260V~ power supply adapter
12/24Vdc power supply cable fitted with a vehicle cigarette
lighter plug
OPTIONS External loudspeaker
Rigid transport case
ACCESSORIES GSMD-FPK
Field Programming Key.
Direct connection to the
Headphone control unit connector.
GSMD-VBR
Vibration Signalling Device
GSMD-HELMET-RDU
Remote Visual/Acoustic slim line signalling device
GSMD-TK
Technical Maintenance Tool Kit. It includes all tools required
for any maintenance and repair requirements
GSMD-TPS
Test Pieces Set.
It includes various reference samples, designed to test the
detection of samples at different depths
V2:
The CMD V2 is a very high performance, high-sensitivity Compact Dual-Sensor system designed to detect
metal and minimum-metal content targets in conductive and non-conductive soils, including laterite and
magnetite, as well as a wide range of unconventional targets such as conductive non-metallic devices
(e.g. carbon rods), wires and mercury switches.
The CMD V2 does not require any manual calibration; in addition,
optimum sensitivity is ensured over all types of terrain due to
CEIA’s Exclusive Automatic Soil Compensation System.
POWER SUPPLY Types of batteries (2x), ANSI Standard, type C
1.2V Ni-MH rechargeable - 1.5V Alkaline (LR14)
BATTERY LIFE AT 20°C
(DEFAULT SEARCH PROGRAM)
with Ni-MH (6000 mAh) rechargeable batteries: 8 hours
with alkaline batteries: 6 hours
Battery charge indicator
METAL ALARM Adjustable sensitivity
Audible alarm with adjustable volume and visual LED display
(maskable with a snap-down infrared cover)
CARBON ROD ALARM Adjustable sensitivity
Specific audible alarm with adjustable volume and visual LED
display (maskable with a snap-down infrared cover)
DIMENSIONS Search head: 13.8” x 5.5”
Folded: 15.3” x 6.2” x 3”
Fully extended: 50.8”
Carry bag: 15.6” x 8” x 4.3”
WEIGHT Metal Detector without batteries: 4.37 lbs
batteries included: 4.6 lbs
Carry bag: 1.2 lbs
Headphone: 0.37 lbs
OPERATING TEMPERATURE -51°F to 158°F
STORAGE TEMPERATURE -67°F to 185°F
LEVEL OF PROTECTION IP68 (IEC 529)
Carry bag in water resistant synthetic canvas
SET-UP TIME Twenty seconds typical (batteries already in place)
BUILT-IN BATTERY CHARGER
POWER SUPPLY
90-260V~ power supply adapter
12/24Vdc power supply cable fitted with a vehicle cigarette
lighter plug
OPTIONS External loudspeaker
Rigid transport case
ACCESSORIES GSMD-FPK
Field Programming Key.
Direct connection to the
Headphone control unit connector.
GSMD-VBR
Vibration Signalling Device
GSMD-HELMET-RDU
Remote Visual/Acoustic slim line signalling device.
GSMD-TK
Technical Maintenance Tool Kit.It includes all tools required for any
maintenance and repair requirements
GSMD-TPS
Test Pieces Set. It includes various reference samples, designed to
test the detection of samples at different depths.
