The ESI/RM4 series is a small 4-channel shock tube initiator designed to be mounted on and powered by an EOD robot.
The included standard mounting kit will mount on a 3"x3" arm. The ESI/RM4-HD has a mounting configuration designed to mount on Remotec's HD-1.
Approvals Certified by USAF Nonnuclear Munitions Safety Board (NNMSB) for USAF EOD operational use. USAF log number: 04-2-8
U.S. Navy Certified to MIL-STD-461E
Weight 1.2 lbs
Size 5.7" x 3.7" x 2.0"
Operating Temperature -40Â°C to +85Â°C
Power Requirements 18 - 30VDC, 300mA for 3 seconds
